Registry settings
The registry settings described below assist in configuring and troubleshooting the product.
| HKLM\Software(\Wow6432Node)\FabulaTech\USB for Remote Desktop (Server) | |||||
|---|---|---|---|---|---|
| Value name | Type | Range | Default | If none [*] | Description |
| CheckForNewVersion | REG_DWORD | 0,1 | 1 | 1 | 0 - Never check for new version. 1 - Check for new version every 15 days. |
| HKLM\SOFTWARE\Fabulatech\SMenu | |||||
|---|---|---|---|---|---|
| Value name | Type | Range | Default | If none [*] | Description |
| IncludeProcesses | REG_SZ | app1.exe,app2.exe,app3.exe | Not exists | Load ftsmenu.dll into enumerated processes app1.exe,app2.exe,app3.exe | |
| HKLM\Software\FabulaTech\USB for Remote Desktop (Server) | |||||
|---|---|---|---|---|---|
| Value name | Type | Range | Default | If none [*] | Description |
| LogLevel | REG_DWORD | 0-3 | 0 | 0 | USB for Remote Desktop (Server) logging level: 0 - Error 1 - Warning 2 - Info 3 - Debug. |
|
Should be set both: HKLM\Software\FabulaTech\Netlink 3 HKLM\Software\Wow6432Node\FabulaTech\Netlink 3 |
|||||
|---|---|---|---|---|---|
| Value name | Type | Range | Default | If none [*] | Description |
| LogLevel | REG_DWORD | 0-3 | 1 | 1 | NetLink logging level: 0 - Error. 1 - Warning. 2 - Info. 3 – Debug. |
| HKLM\SYSTEM\CurrentControlSet\services\ftusbrdsrv | |||||
|---|---|---|---|---|---|
| Value name | Type | Range | Default | If none [*] | Description |
| HIDFilter | REG_DWORD | 0-1 | Not exists | 1 | Block or allow redirection of all HID devices. 0 – Allow 1 – Block |
| HKLM\SYSTEM\CurrentControlSet\services\ftusbrdsrv\HIDFilterException | |||||
|---|---|---|---|---|---|
| Value name | Type | Range | Default | If none [*] | Description |
| VID:PID | REG_DWORD | 0-1 | Not exists | Block or allow redirection of specific HID device, identified by it's VID:PID (hexadecimal format, without leading zeros). 0 – Allow 1 – Block Example of value name: 46D:C077 |
|
| HKLM\SOFTWARE\FabulaTech\FtSoundIsolation | |||||
|---|---|---|---|---|---|
| Value name | Type | Range | Default | If none [*] | Description |
| IsolationMode | REG_DWORD | 0−2 | 2 | 2 | Audio device isolation mode: 0 - Strict 1 - Session-isolated (compatible) 2 - No isolation. Important: Changes to this setting apply only to new user sessions. Users must sign out and sign in again for the new setting to take effect. |
Advanced registry settings
These settings are intended for some specific hardware or use cases and should not be changed unless necessary.
| HKLM\SYSTEM\CurrentControlSet\services\ftusbrdsrv | |||||
|---|---|---|---|---|---|
| Value name | Type | Range | Default | If none [*] | Description |
| ESeekImageQuality | REG_DWORD | 0-100 | Not exists | 75 | Configures the output image size of the E-Seek M500 ID card scanner by controlling image compression (0–100). - At 100, the image has the maximum size and highest quality, with no compression. - Lower values result in stronger compression, reducing the scanned image size and scanning time. - The default value is 75. |
Notes:
[*] - If the value does not exist, the program defaults to this value.
